Impressive performance with easy operation: the LCD (Silver model) or TFT display (Gold model) enables intuitive operation. Both thermostat heads offer a six-stage circulation pump and can be expanded with numerous interface modules as accessories.
The extensive model portfolio offers types with cooling output of 180 to 700 watts and minimum temperatures of -15 to -50°C.
The high-performance LAUDA ECO devices work with the energy-saving LAUDA SmartCool system, which automatically adjusts the cooling output to the required operating status.
The cooling thermostats come with bath cover and pump connections as standard, and are available in air and water-cooled designs. A drain tap on the back side of the device makes changing the heat transfer liquid easy and safe.
Working temperature min.
-50 °C
Max. working temperature
200 °C
Temperature stability
0.02 ± K
Select up to 4 technical parameters that you want to display in the table
| Product | Min. temperature range | Max. working temp | Heating output | Cooling output at 20 °C 50 Hz | Compare product | |
|---|---|---|---|---|---|---|
| ECO RE 415 G | -15 °C | 200 °C | 2.6 kW | 0.18 kW | Details | |
| ECO RE 415 GW | -15 °C | 200 °C | 2.6 kW | 0.18 kW | Details | |
| ECO RE 415 S | -15 °C | 200 °C | 2 kW | 0.18 kW | Details | |
| ECO RE 415 SW | -15 °C | 200 °C | 2 kW | 0.18 kW | Details | |
| ECO RE 420 G | -20 °C | 200 °C | 2.6 kW | 0.2 kW | Details | |
| ECO RE 420 S | -20 °C | 200 °C | 2 kW | 0.2 kW | Details | |
| ECO RE 630 G | -30 °C | 200 °C | 2.6 kW | 0.3 kW | Details | |
| ECO RE 630 S | -30 °C | 200 °C | 2 kW | 0.3 kW | Details | |
| ECO RE 1050 G | -50 °C | 200 °C | 2.6 kW | 0.7 kW | Details | |
| ECO RE 1050 S | -50 °C | 200 °C | 2 kW | 0.7 kW | Details | |
| ECO RE 1225 G | -25 °C | 200 °C | 2.6 kW | 0.3 kW | Details | |
| ECO RE 1225 S | -25 °C | 200 °C | 2 kW | 0.3 kW | Details | |
| ECO RE 2025 G | -25 °C | 200 °C | 2.6 kW | 0.3 kW | Details | |
| ECO RE 2025 S | -25 °C | 200 °C | 2 kW | 0.3 kW | Details |
| Device | Device category | Document type | Language | Format | File size | |
|---|---|---|---|---|---|---|
| ECO Silver | Immersion thermostats | Operating instruction |
English
| 4,49 MB |
Download document
| |
| ECO Silver | Bath thermostats | Operating instruction |
English
| 4,49 MB |
Download document
| |
|
ECO Silver Natural refrigerant | Bath thermostats | Operating instruction |
English
| 4,41 MB |
Download document
| |
| ECO Gold | Immersion thermostats | Operating instruction |
English
| 5,5 MB |
Download document
| |
| ECO Gold | Bath thermostats | Operating instruction |
English
| 5,5 MB |
Download document
| |
|
ECO Gold Natural refrigerant | Bath thermostats | Operating instruction |
English
| 5,3 MB |
Download document
| |
|
Chapter Cooling thermostats Overall brochure | Bath thermostats | Brochure |
English
| 2,6 MB |
Download document
| |
|
Chapter Heating thermostats Overall brochure | Bath thermostats | Brochure |
English
| 3,35 MB |
Download document
| |
|
Chapter Calibration thermostats Overall brochure | Special devices | Brochure |
English
| 1,52 MB |
Download document
|
