制冷恒温器 Proline Kryomate RP 4090 C

Proline Kryomate RP 4090 C

Proline Kryomate 分为风冷或水冷规格，浴槽开口大，并且浴槽容量为 30 或 40 升。

订购编号: L001687

咨询产品

返回至概览制冷恒温器

性能特征

Thermostatic bath/circulator with latest microprocessor technology and integrated cooling system

Input either via cursor keys, numeric soft keys or both. Additional Tmax key for overtemperature

SelfCheck Assistant for system diagnosis

Low level and overtemperature protection for use with non-flammable liquids

Programmer with 150 temperature/time segments that can be separated into 5 programs

Adjustment of bath circulation according to application

SmartCool system for energy-saving digital cooling management including compressor on-off control

Utilises traditional refrigerants (HFCs) in accordance with European legislation to control F-gases (EU) 573/2024

Back-lit graphic LCD display with high resolution and different display modes

Command console can be detached and used as remote control

Fully electronic continuous controller with PID action for internal & external control

Optically decoupled RS 232/485 interface integrated as a standard

Timer function for switching on the thermostat, entering the standyby mode or running of programs

Pump connectors on the side and in the back, installed bypass

Electronically-controlled heating of bath edge and bath bridge prevents moisture in the atmosphere from condensing and freezing at low temperatures

Additional green LED display for temperature

EasyUse system for simple operation of the whole unit

PowerAdapt system for the use of the maximum possible amount of heat permitted by the power supply system

Option for upgrading with up to 2 interfaces (RS 232/485, Profibus, analogue or contact modules, Ethernet-USB module)

LAUDA Vario pump with 4 selectable output steps

With addional pump for external application (Thread M 30 x 1.5 O)

Condenser cooling Air

工作范围

最小工作温度

-90 °C

最大工作温度

150 °C

温度稳定性

0.05 ± K

技术特征

工作温度范围

-90 ... 150 °C

环境温度范围

5 ... 40 °C

温度稳定性

0.05 ± K

最大加热功率

3 kW

最大功率消耗

7 kW

电流消耗

25 A

最大输送压力

0,9 bar

泵最大输送流量（压力）

90 L/min

最小/最大浴槽容积

32,0 / 44,0 L

尺寸（宽x深x高）

600 x 700 x 1216 mm

重量

165 kg

电源供应

208 V; 3/PE; 60 Hz

电源插头

不带插头的电源线 (HAR)

温度	泵级	回火介质	冷却能力 60 赫兹
200 °C	2	传热油	3 kW
20 °C	2	乙醇	2.9 kW
0 °C	2	乙醇	2.8 kW
-20 °C	2	乙醇	2.4 kW
-30 °C	2	乙醇	2.2 kW
-40 °C	2	乙醇	1.9 kW
-50 °C	2	乙醇	1.5 kW
-60 °C	2	乙醇	1.2 kW
-70 °C	2	乙醇	0.7 kW
-80 °C	2	乙醇	0.4 kW
-90 °C	2	乙醇	0.05 kW

数据表 Proline Kryomate RP 4090 C

下载 - 一般产品数据

设备	设备类别	文件类型	语言	格式	尺寸
Chapter Cooling thermostats Overall brochure Chinese	恒温浴槽	产品说明手册	中文	PDF	4,63 MB	下载文档
