The PRO low-temperature bath thermostats for internal bath applications offer a working temperature range from -100 to 200°C. A multi-stage adjustable pump ensures excellent homogeneity of the bath. With their bath sizes from 10 to 30 liters and cooling capacity from 0.4 to 1.5 kW, the low temperature thermostats are suitable for a wide range of applications.
Min. working temperature
-100 °C
Max. working temperature
200 °C
Temperature stability
0.01 ± K
| Temperature | Pump level | Tempering medium | Cooling capacity 50 Hz |
|---|---|---|---|
| 20 °C | 8 | Ethanol | 0.4 kW |
| 10 °C | 8 | Ethanol | 0.4 kW |
| 0 °C | 8 | Ethanol | 0.4 kW |
| -10 °C | 8 | Ethanol | 0.4 kW |
| -20 °C | 4 | Ethanol | 0.4 kW |
| -30 °C | 4 | Ethanol | 0.39 kW |
| -40 °C | 4 | Ethanol | 0.37 kW |
| -50 °C | 4 | Ethanol | 0.35 kW |
| -60 °C | 4 | Ethanol | 0.32 kW |
| -70 °C | 4 | Ethanol | 0.25 kW |
| -80 °C | 4 | Ethanol | 0.17 kW |
| -85 °C | 4 | Ethanol | 0.12 kW |
| -90 °C | 4 | Ethanol | 0.06 kW |
| -95 °C | 4 | Ethanol | 0.02 kW |
| -100 °C | 4 | Ethanol | 0.01 kW |
