Mobifreeze M 270

Keeping the cold chain controlled during transportation thanks to a constant temperature – with our new Mobifreeze product, we have managed to turn our vision into reality. The battery-powered and mobile ultra low temperature chest freezer sets new standards in the field of intralogistics.

Order no.: L003678
Inquire about product
Back to overview Mobile freezers

Features

Actively tempered, mobile ultra-low freezer for safe maintenance of the cold chain in intralogistics and for factory transport in road logistics
Flexible change between mains and battery operation possible, automatic charging when mains connection
Interior completely made of stainless steel
One feed-through with an internal diameter of 13 mm as standard, for the introduction of external control sensors
Bridging of transport phases up to 4 hours without power supply at - 80 °C storage temperature
Comfortable touchscreen control unit with digital display for entering and calling up all safety-relevant values
Energy-saving, maintenance-free refrigeration system with fully hermetic high-performance compressors
Powerful battery with increased protection against overheating (lithium iron phosphate battery technology)
Display and alarm functions are maintained in the event of a power failure (battery backup)
Additional insulating cover plates over the usable space

Working range

Min. working temperature

-86 °C

Max. working temperature

-50 °C

Temperature stability

3 ± K

Technical data (according to DIN 12876)

Working temperature range
-86 ... -50 °C
Temperature stability
3 ± K
Ambient temperature range
15 ... 28 °C
Usable volume
270 L
Interior dimensions (WxDxH)
900 x 600 x 500 mm
Dimensions (WxDxH)
1471 x 933 x 1217 mm
Weight
325 kg
Cool down time
from 20 °C to -80 °C in 3 h
Thawing time
from -80 °C to 0 °C in 10 h
Power supply
230 V; 50 Hz
Power plug
Power cord with plug (CEE7/7)
