Cooling thermostats

Sustainable temperature control from -100 to 200 °C

Cooling thermostats

LAUDA Cooling thermostats are sustainable from the get-go. The ECO devices can be operated with natural refrigerants as standard and the PRO line enables hybrid cooling with water. Together, these low-temperature thermostats cover a temperature range from -100 °C to 200 °C and they are available with bath volumes of 3.3 to 44 L. There are four product lines with different focal points and power models, so that you can find the best model for your application - regardless of whether for sample preparation in chemistry and pharmaceuticals, for vale and component tests, stress tests and much more.
Inquire about product line

LAUDA Cooling thermostats

Overview of all cooling thermostats

Cooling thermostats product lines

Alpha Cooling thermostats

Alpha Cooling thermostats

Affordable cooling thermostats for maintaining temperatures from -25 to 100 °C in the lab

Cooling output from 0.225 kW to 0.425 kW

Heating output from 1 kW to 1.5 kW

-100
-50
0
50
100
150
200
250
300
-25 to 100 °C
Alpha Cooling thermostats
ECO Cooling thermostats

ECO Cooling thermostats

From -50 to 200 °C: Cooling thermostats for economical temperature control in the lab

Cooling output from 0.18 kW to 0.7 kW

Heating output from 1 kW to 2.6 kW

-100
-50
0
50
100
150
200
250
300
-50 to 200 °C
ECO Cooling thermostats
PRO Cooling thermostats

PRO Cooling thermostats

Cooling bath thermostats for professional temperature control thermostating from -100 to 200 °C

Cooling output from 0.8 kW to 1.5 kW

Heating output from 1.3 kW to 3.6 kW

-100
-50
0
50
100
150
200
250
300
-100 to 200 °C
PRO Cooling thermostats
Proline Kryomate Cooling thermostats

Proline Kryomate Cooling thermostats

Professional cooling thermostats from -90 to 200 °C for use in process technology and material inspection

Cooling output from 2.9 kW to 6 kW

Heating output from 2.8 kW to 3.5 kW

-100
-50
0
50
100
150
200
250
300
-90 to 200 °C
Proline Kryomate Cooling thermostats

DO YOU NEED ADDITIONAL INFORMATION OR DO YOU HAVE QUESTIONS?


International Area Sales

+49 9343 503-555
E-Mail

Overview of all device types

Select the desired working temperature, product line, or type of heat discharge to narrow down the list

Application type

Working temperature (°C)

Product line
Heat discharge
ProductMin. working tempMax. working tempHeater power max.Cooling output at 20 °C 60 HzCompare product
Alpha RA 8 -25 °C 100 °C 1.5 kW 0.225 kW
Alpha RA 12 -25 °C 100 °C 1.5 kW 0.325 kW
Alpha RA 24 -25 °C 100 °C 1.5 kW 0.425 kW
ECO RE 415 G -15 °C 200 °C 2.4 kW 0.18 kW
ECO RE 415 GW -15 °C 200 °C 2.4 kW 0.18 kW
ECO RE 415 S -15 °C 200 °C 0.18 kW
ECO RE 415 SW -15 °C 200 °C 1.8 kW 0.18 kW
ECO RE 420 G -20 °C 200 °C 1.3 kW 0.2 kW
ECO RE 420 S -20 °C 200 °C 1.3 kW 0.2 kW
ECO RE 630 G -30 °C 200 °C 2.4 kW 0.3 kW
ECO RE 630 S -30 °C 200 °C 1.8 kW 0.3 kW
ECO RE 1050 G -50 °C 200 °C 0.7 kW
ECO RE 1050 S -50 °C 200 °C 1.8 kW 0.7 kW
ECO RE 1225 G -25 °C 200 °C 2.4 kW 0.3 kW
ECO RE 1225 S -25 °C 200 °C 1.8 kW 0.3 kW
ECO RE 2025 G -25 °C 200 °C 2.4 kW 0.3 kW
ECO RE 2025 S -25 °C 200 °C 1.8 kW 0.3 kW
Proline Kryomate RP 3090 C -90 °C 150 °C 3 kW 2.9 kW
Proline Kryomate RP 3090 C -90 °C 200 °C 3 kW 3 kW
Proline Kryomate RP 3090 CW -90 °C 150 °C 3 kW 3.9 kW
Proline Kryomate RP 3090 CW -90 °C 200 °C 3 kW 4 kW
Proline Kryomate RP 4050 C -50 °C 150 °C 3 kW 4.9 kW
Proline Kryomate RP 4050 C -50 °C 200 °C 3 kW 5 kW
Proline Kryomate RP 4050 CW -50 °C 200 °C 3 kW 6 kW
Proline Kryomate RP 4090 C -90 °C 150 °C 3 kW 2.9 kW
  • 1
  • 2

Applications and industry examples for LAUDA thermostats

Botanic extraction

Botanic extraction

Temperature control helps extract target compounds efficiently, prevent contamination and improve solubility.

To the application example
Research & development labs

Research & development labs

Temperature control in research and development is especially important in the sample preparation and quality assurance sectors.

To the application example
Pharmaceutical industry

Pharmaceutical industry

In the pharmaceutical industry, temperature control processes range from research to production scale.

To the application example
