Process thermostats for the effective monitoring of external temperature control processes in temperatures ranging from -30 to 150°C.
LAUDA Integral T process thermostats are optimally suited to the effective monitoring of external temperature control processes in temperatures ranging from -30 to 150°C. These devices enable rapid temperature changes thanks to tailored heating and cooling output with small internal volumes.
Thanks to the open hydraulic system, the device aerates quickly and without loss of function. This makes it ideal for temperature control processes with frequent changes in consumer or test object. A reliable, powerful submersible pump and an internal bypass to limit the pressure are
part of the Integral T's standard equipment. The modular interface concept is now also implemented in the Integral T and ensures maximum networking of user processes.
Overview
Benefits and added value
-
Quick aeration and outgassing, as well as high output and working pressures
-
Preventive protection for pressure-sensitive consumers
-
Heating and cooling functions work independently of the flow rate for the application. The flow can be interrupted, e.g. when changing consumers
-
Remote monitoring and maintenance via LAUDA.LIVE
![](/fileadmin/_processed_/5/4/csm_LAUDA_Integral_IN130T_1853924b73.png)
Working range
With the modular interface concept, you can integrate the new Integral process thermostats into your processes with maximum flexibility. The devices are equipped as standard with interfaces such as Ethernet, USB or Pt 100. Additional interfaces and communication protocols can be easily added via modules.
![Working temperature min.](/pim/image/L002665/icon-produkt-arbeitstemperatur-min.png)
Working temperature min.
-30 °C
![Max. working temperature](/pim/image/L002665/icon-produkt-arbeitstemperatur-max.png)
Max. working temperature
120 °C
![Temperature stability](/pim/image/L002665/icon-produkt-temperaturkonstanz.png)
Temperature stability
0.05 ± K
Product lines
Select up to 4 technical parameters that you want to display in the table
Product | Min. temperature range | Max. working temp | Heating output | Cooling output at 20 °C 50 Hz | Compare product | |
---|---|---|---|---|---|---|
Integral IN 130 T | -30 °C | 120 °C | 2.7 kW | 1.4 kW | Details | |
Integral IN 230 T | -30 °C | 120 °C | 2.7 kW | 2.2 kW | Details | |
Integral IN 230 TW | -30 °C | 120 °C | 2.7 kW | 2.3 kW | Details | |
Integral IN 530 T | -30 °C | 120 °C | 8 kW | 5 kW | Details | |
Integral IN 530 TW | -30 °C | 120 °C | 8 kW | 6 kW | Details | |
Integral IN 1030 T | -30 °C | 150 °C | 8 kW | 11 kW | Details | |
Integral IN 1330 TW | -30 °C | 150 °C | 16 kW | 13 kW | Details | |
Integral IN 1830 TW | -30 °C | 150 °C | 16 kW | 19 kW | Details |
Device dimensions
![](/pim/_processed_/c/2/csm_lau_Integral_130_T_230_T_-230_TW_-150_XT_250_XTW_d2d8b6ab10.png)
![](/pim/_processed_/e/7/csm_lau_Integral_280_XT_280_XTW_-530_T_530_TW_550_XT-550_XTW_750_XT_950_XTW_9966a4c62c.png)
![](/pim/_processed_/0/e/csm_lau_Integral_590_1030_1330_1850_1590_965eac96e8.png)
