LAUDA Integral XT process thermostats operate according to the flow principle with a cold oil blanket that enables the utilization of temperature control media over a significantly larger temperature range—optimal for dynamic temperature control tasks.
The electronically controlled, magnetically coupled pump can set the flow rate optimally both for the requirements of pressure-sensitive consumers and for applications with high hydraulic resistance.
A modular interface concept that is fit for the future ensures maximum networking of user processes. In addition, the Integral devices are already designed to use LAUDA.LIVE, a digital solution for remote maintenance and monitoring - for greater safety and reliability.
Operate your Integral process thermostat simply via a modern TFT display directly on the device or optionally via an intuitive operating unit with touch display and extended range of functions.
Min. working temperature
25 °C
Max. working temperature
320 °C
Temperature stability
0.1 ± K
Select up to 4 technical parameters that you want to display in the table
| Product | Min. working temp | Max. working temp | Heater power max. | Cooling output at 20 °C 60 Hz | Compare product | |
|---|---|---|---|---|---|---|
| Integral IN 4 XTW | 25 °C | 320 °C | 3.3 kW | 2 kW | Details | |
| Integral IN 8 XTW | 25 °C | 320 °C | 8 kW | 2 kW | Details | |
| Integral IN 150 XT | -45 °C | 220 °C | 3.3 kW | 1.5 kW | Details | |
| Integral IN 250 XTW | -45 °C | 220 °C | 3.4 kW | 2.1 kW | Details | |
| Integral IN 280 XT | -80 °C | 220 °C | 4 kW | 1.6 kW | Details | |
| Integral IN 280 XTW | -80 °C | 220 °C | 4 kW | 1.7 kW | Details | |
| Integral IN 550 XT | -50 °C | 220 °C | 8 kW | 5 kW | Details | |
| Integral IN 550 XTW | -50 °C | 220 °C | 8 kW | 5.8 kW | Details | |
| Integral IN 590 XTW | -90 °C | 220 °C | 8 kW | 4.5 kW | Details | |
| Integral IN 750 XT | -45 °C | 220 °C | 8 kW | 7 kW | Details | |
| Integral IN 950 XTW | -50 °C | 220 °C | 8 kW | 9.5 kW | Details | |
| Integral IN 1590 XTW | -90 °C | 220 °C | 12 kW | 18.5 kW | Details | |
| Integral IN 1850 XTW | -50 °C | 220 °C | 16 kW | 20 kW | Details | |
| Integral IN 2560 XTW | -60 °C | 220 °C | 24 kW | 28 kW | Details |
